GY-CS ULTIMATE THREADING TAPS SET

Our Complete Tap & Round Die Box is a comprehensive professional solution for precision threading and cutting tasks. Engineered for versatility, this set is meticulously organized in a fine finished wooden box that ensures tool protection and easy accessibility for industrial or workshop use.

Key Features

  • Comprehensive Threading Range: Available in a vast array of thread standards including BSW, BSF, UNF, UNC, MM, BA, BSP, NPT, BSPT, and BSPF.
  • High-Quality Components: Each set includes a full range of taps and matching round dies in suitable diameters to ensure precise compatibility.
  • Professional Tooling: Kits come equipped with high-performance Round Die Handles (Circular Die Stocks) and adjustable Tap Handles (Tap Wrenches) tailored to the specific size range of the set.
  • Durable Presentation: All tools are securely housed in a premium, fine-finished storage box designed for long-term durability.

Technical Specifications

We offer a diverse range of configurations to meet specific threading requirements:
Standards Covered Size Ranges Available No. of Sizes per Set
Imperial (BSW, BSF, UNF, UNC) 1/16″ to 1 – 1/2″ 5 to 12 Sizes
Metric (MM) 2mm to 30mm 5 to 13 Sizes
British Association (BA) 0 to 10 BA 7 to 11 Sizes
Pipe Threads (BSP, NPT, BSPT, BSPF) 1/8″ to 1 – 1/2″ 6 to 10 Sizes

Customization & Support

  • Bespoke Sets: Special sizes of complete sets can be supplied against specific orders to match your unique technical requirements.
  • Flexible Packaging: We can supply different sizes and styles of boxes based on customer preferences.
Whether you are performing maintenance, automotive repair, or industrial manufacturing, these tap and die sets provide the accuracy and reliability needed for clean, professional threads every time.

BSW BSF UNF UNC
TECHNICAL SPECIFICATION
Set No. Range of Sizes – One Set Each of Tap & One Piece each of Round Die in suitable Dia Round Die Handle (Circular Die Stock) Outer Diameter Tap Handle (Tap Wrench) Inches No. Of Sizes
13/16 Inch 1 Inch 1 1/2 Inch 2 Inch
201 1/16, 3/32, 1/8, 5/32, 3/16, 7/32, 1/4 BSW 1/16 to 1/4 —- —- —- 1/4 7
203 1/8, 5/32, 3/16, 7/32, 1/4 BSW 1/8 to 1/4 —- —- —- 1/4 5
205 1/4, 5/16, 3/8, 7/16, 1/2 BSW —- 1/4 to 3/8 7/16 to 1/2 —- 1/2 5
207 1/4, 5/16, 3/8, 7/16, 1/2 BSF —- 1/4 to 3/8 7/16 to 1/2 —- 1/2 5
209 1/4, 5/16, 3/8, 7/16, 1/2 UNF —- 1/4 to 3/8 7/16 to 1/2 —- 1/2 5
210 1/4, 5/16, 3/8, 7/16, 1/2 UNC —- 1/4 to 3/8 7/16 to 1/2 —- 1/2 5
211 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4 BSW —- 1/4 to 3/8 7/16 to 3/4 —- 3/4 7
213 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4 BSF —- 1/4 to 3/8 7/16 to 3/4 —- 3/4 7
215 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4 UNF —- 1/4 to 3/8 7/16 to 3/4 —- 3/4 7
216 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4 UNC —- 1/4 to 3/8 7/16 to 3/4 —- 3/4 7
217 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1 BSW —- 1/4 to 3/8 7/16 to 3/4 7/8 to 1 1/2 & 1 9
219 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1 BSF —- 1/4 to 3/8 7/16 to 3/4 7/8 to 1 1/2 & 1 9
221 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1 UNF —- 1/4 to 3/8 7/16 to 3/4 7/8 to 1 1/2 & 1 9
222 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1 UNC —- 1/4 to 3/8 7/16 to 3/4 7/8 to 1 1/2 & 1 9
MM BA BSW
TECHNICAL SPECIFICATION
Set No. Range of Sizes – One Set Each of Tap & One Piece each of Round Die in suitable Dia Round Die Handle (Circular Die Stock) Outer Diameter Tap Handle (Tap Wrench) Inches No. Of Sizes
13/16 Inch 1 Inch 1 ½ Inch 2 Inch 2-1/4 Inch 3 Inch
223 2, 3, 4, 5, 6 mm 2 to 6 —- —- —- —- —- 1/4 5
224 2, 3, 4, 5, 6, 7, 8, 9, 10 mm 2 to 6 7 to 10 —- —- —- —- 1/2 9
225 6, 7, 8, 10, 12 mm —- 6 to 10 12mm —- —- —- 1/2 5
227 6, 8, 10, 12, 14, 16, 18 mm —- 6 to 10 12 to 18 —- —- —- 3/4 7
228 6, 8, 10, 12, 14, 16, 18, 20 mm —- 6 to 10 12 to 20 —- —- —- 3/4 8
229 6, 8, 10, 12, 14, 16, 18, 20, 22, 24 mm —- 6 to 10 12 to 18 20 to 24 —- —- 1/2 & 1 10
230 6, 8, 10, 12, 14, 16, 18, 20, 22, 24, 26, 28, 30mm —- —- 6 to 18 20 to 24 26 to 30 —- 1/2 & 1-1/8 13
231 0, 1, 2, 3, 4, 5, 6 BA 0 to 6BA —- —- —- —- —- 1/4 7
233 0, 1, 2, 3, 4, 5, 6, 7, 8 BA 0 to 8BA —- —- —- —- —- 1/4 9
235 0, 1, 2, 3, 4, 5, 6, 7, 8, 9, 10 BA 0 to 10BA —- —- —- —- —- 1/4 11
240 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1, 1-1/8, 1-1/4 BSW —- —- 1/4 to 3/4 —- 7/8 to 1 1/4 —- 1/2 & 1-1/8 11
244 1/4, 5/16, 3/8, 7/16, 1/2, 5/8, 3/4, 7/8, 1, 1-1/8, 1-1/4, 1 1/2 BSW —- —- 1/4 to 3/4 —- 7/8 to 1 1/4 1 1/2 1/2 & 1 1/2 12
BSP NPT BSPT BSPF
TECHNICAL SPECIFICATION
Set No. Range of Sizes – One Set Each of Tap & One Piece each of Round Die in suitable Dia Round Die Handle (Circular Die Stock) Outer Diameter Tap Handle (Tap Wrench) Inches No. Of Sizes
1 ½ Inch 2 Inch 2-1/4 Inch 3 Inch
260 1/8, 1/4, 3/8, 1/2, 3/4, 1 BSP 1/8 to 3/8 1/2 to 3/4 1 3/4 & 1 ¼ 6
262 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1-1/4 BSP 1/8 to 3/8 1/2 to 3/4 —- 1 & 1 ½ 9
264 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1-1/4, 1½ BSP 1/8 to 3/8 1/2 to 3/4 —- 7/8 to 1½ 1 & 2 10
266 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1-1/8, 1¼ BSP 1/8 to 3/8 1/2 to 3/4 —- 7/8 to 1¼ 1 & 1½ 10
268 1/8, 1/4, 3/8, 1/2, 3/4, 1, 1-1/4 BSP 1/8 to 3/8 1/2 to 3/4 —- 1 to 1¼ 1 & 1½ 7
270 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1 BSP 1/8 to 3/8 1/2 to 3/4 7/8 to 1 —- 3/4 & 1½ 8
272 1/8, 1/4, 3/8, 1/2, 3/4, 1, 1-1/4, 1½ BSP 1/8 to 3/8 1/2 to 3/4 —- 1 to 1½ 1 & 2 8
274 1/8, 1/4, 3/8, 1/2, 3/4, 1 NPT 1/8 to 3/8 —- 1/2 to 1 —- 3/4 & 1½ 6
276 1/8, 1/4, 3/8, 1/2, 3/4, 1 BSPT 1/8 to 3/8 —- 1/2 to 1 —- 3/4 & 1½ 6
278 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1 BSPF 1/8 to 3/8 1/2 to 3/4 —- 7/8 to 1 3/4 & 1½ 8
280 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1-1/4 BSPF 1/8 to 3/8 1/2 to 3/4 —- 7/8 to 1¼ 1 & 1½ 9
282 1/8, 1/4, 3/8, 1/2, 5/8, 3/4, 7/8, 1, 1-1/4, 1½ BSPF 1/8 to 3/8 1/2 to 3/4 —- 7/8 to 1½ 1 & 2 10
