PRECISION SELF CENTERING 5 AXIS VISE

This self-centering 5-axis vice is engineered for high-precision CNC rotary table applications. Whether integrated into horizontal or vertical machining setups, it provides the stability required for complex 4 and 5-axis operations. While optimized for CNC use, its versatility makes it a staple for precision milling and grinding tasks where accuracy is non-negotiable.

Maximum Machining Versatility

Low-Profile Design: The compact footprint is engineered for rotary tables and machining centers, maximizing your workspace and providing superior tool accessibility.
5-Axis Ready: Securely grip workpieces with minimal surface area, allowing for unobstructed 5-side machining in a single setup.

Uncompromising Accuracy

Repeatable Precision: Maintains a centering accuracy of ±0.02mm and squareness within ±0.01/100mm.
Anti-Float Technology: The integrated “Lock Tight” system prevents workpiece lift during clamping, ensuring stable, high-efficiency machining.

Industrial Durability

Premium Construction: Crafted from high-quality alloy steel and case-hardened to HRC 60 ± 2 for long-term wear resistance.
Smart Maintenance: The unique body architecture facilitates rapid chip evacuation and efficient coolant drainage, keeping your workflow clean and continuous.
